Commands Listed in Alphabetical Order
Syntax
DISplay:FORMa
t {YT|XY| XYZ}
DISplay:FORMat?
Arguments
YT sets the display to a voltage versus time format and is the d efault mode.
XY argument displays one waveform against another. The source pairs that make
up an XY trac e are predefined and are listed in the following table. Selecting one
source causes its corresponding source to be implicitly selected, producing a
single trace from the two input waveforms.
XYZ argument is available only for four-channel instruments. The argument
combines channel 1 and channel 2 for X a nd Y coordinates and uses channel 3 to
provide the intensity value for the sample. XYZ groups channels 1, 2 and 3 to
form a single trace. Other channel, math, and reference waveforms are turned off.
Table 2-16: XY Format Pairs
X-Axis Source Y-Axis Source
CH 1 CH 2
CH 3 CH 4
Ref1 Ref2
Ref3 Ref4
Examples
DISPLAY:FORMAT YT selects a voltage versus time format for the display.
DISPLAY:FORMAT? might return :DISPLAY: FORMAT XY is for the display
format, indicating that the display is in the XY mode.
DISplay:GRAticule
This command selects or queries the type of graticule that is displayed. This
command is equivalent to selecting Graticule Style from the Display menu.
Group
Display Control
Syntax
DISplay:GRAticule
{CROSSHair|FRAme|FULl|GRI d|IRE|NTSC|MV|PAL}
DISplay:GRAticule?
Arguments
CROSSHair specifies a frame and cross hairs.
FRAme specifies a frame only.
FULl specifi es a frame, a grid and cross hairs.
2-188 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
