Commands Listed in Alphabetical Order
DIAg:SELect:
AREA
This command selects or queries an available diagnostic area. This command is
equivalent to selecting Instrument Diagnostics from the Utilities menu and then
selecting an
Area from the pull-down list.
NOTE. This command should be executed only if DIAg:LEVEL is currently set
to AREA.
Group
Diagnostics
Syntax
DIAg:SELect:AREA <NR1>
DIAg:SELect:AREA?
Related Commands
DIAg:SELect:SUBSYS, DIAg:SELect:TEST, DIAg:SELect:LAST
Arguments
<NR1> selects a diagnostic area by number, which can range from 0 (zero selects
all) through 15 (as specified by DIA g:N UMIT
EMS?).
Examples
DIAG:SELECT:AREA 1 selectsArea1astheareatobediagnosed.
DIAG:SELECT:AREA? might return :DIAG:SELECT:ARE A 0, indicating that
all areas are selec ted.
DIAg:SELect:LAST
This command selects one or more diagnostic menu items to be executed
via the DIAg:EXECUTE command. If you specify DIAg:LEVEL SUBS
YS,
then menu items come from this diagnostic level a nd are limited to the
value returned by the DIAg:NUMITEMS? query. Forexample,ifthereturn
from the DIAg:NUMITEMS? query is :DIAG:NUMITEMS 5, specifying
DIAg:SELECT:SUBSYS 2 indicates that diagnostics will start from subsystem 2
and that you can specify a range from 2 through 5 for DIAg:SELect:LAST.
If you enter: DIAg:SELect:LAST 2 , only subsystem 2 will be executed.
DIAg:SELect:LAST 4, subsystems 2 through 4 will be executed.
Group
Diagnostics
Syntax
DIAg:SELect:LAST <NR1>
DIAg:SELect:LAST?
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-173
