Commands Listed in Alphabetical Order
HEADER? might r
eturn
:HEADER 1, indicating that the instrument is including
headers on applicable query responses.
HIStogram? (Query Only)
This query-only command returns all hist ogram parameters; it queries the state
of all histogram parameters that the user can set. This command is equivalent to
selecting Waveform Histograms from the Measure menu.
Group
Histogram
Syntax
HIStogram?
Related Commands
MEASUrement:METHod
Examples
HISTOGRAM? might return the histogram parameters as :HISTOGRAM:BOXPCNT
30.0000,25.1000,70.0000,75 .2000;DISPLAY LINEAR;STATE
1;FUNCTION VERTICAL;SIZE 2.0000;SOURCE CH1
.
HIStogram:BOX
This command d efines or returns the left, top, right, and bottom boundaries of the
histogram box, in source waveform coordinates. This command is equivalent
to selecting Waveform Histograms from the Measure menu and then setting
Limits for Left, Right, Top, and Bottom in the appropriate boxes. The command
is similar to the HIStogram:BOXPcnt command except that command uses
percentage coordinates to define the boundaries of the histogram box.
NOTE. This command implicitly clears the histogram count and statistics for the
histogram and histogram source data when HIStogram:STATE is turned on.
Group
Histogram
Syntax
HIStogram:BOX <NR3>,<NR3>,<NR3>,<NR3>
HIStogram:BOX?
Related Comm
ands
HIStogram:BOXPcnt
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-231
