Commands Listed in Alphabetical Order
can range from 1
through 4. This command is equivalent to selecting Reference
Waveforms from the File menu, choosing Label from the drop-down list, selecting
the tab associated with the reference for which you want to position a label, and
entering a value in the Y Position box.
Group
Vertical
Syntax
REF<x>:LABel:YPOS <NR1>
REF<x>:LABel:YPOS?
Related Commands
REF<x>:LABel?
Arguments
<NR1> is the location (in divisions) where the waveform label for the selected
reference is displayed, relative to the waveform handle. Arguments should be
integers ranging from 10 to -10.
Examples
REF3:LABEL:YPOS -10 moves the waveform label for the Reference 3
waveform 10 divisions below the waveform handle.
REF2:LABEL:YPOS? might return :REF2:LABEL:YPOS 0, indicating that
the waveform label for the Reference 2 waveform is currently located at the
waveform handle.
REF<x>:VERTical:POSition
This command sets or queries the vertical position of a reference waveform The
reference waveform is specified by x. The value of x can range from 1 through 4.
This command is equivalent to selecting Reference Waveforms from the File
menu, choosing Reference Setup from the drop-down list, selecting a reference
waveform, and then entering the Position value using the multipurpose knob.
Increasing the position value of a waveform causes the waveform to move up,
and decreasing the position value causes the waveform to move down. Position
adjusts only the display position of a waveform. The position value determines the
vertical graticule
coordinate at which signal values are displayed. For example, if
the position for Reference 3 is set to 2.0, the signal represented by that reference
will be displayed at 2.0 divisions above the center of the screen.
NOTE. References are static. All position and scale changes are applied in a
post-processing mode.
2-420 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
