Commands Listed in Alphabetical Order
when MEASUreme
nt:MEAS<x>:REFLevel:METHod is set to Percent. Mid1
specifies the “from” waveform and Mid2 specifies the “to” waveform for delay
measurements. Measurements are specified by x, which ranges from 1 through 8.
NOTE. This command affects the results of delay measurements.
Group
Measurement
Syntax
MEASUrement:MEAS<x>:REFLev el:PERCent:MID<x> <NR3>
MEASUrement:MEAS<x>:REFLev el:PERCent:MID<x>?
Related Commands
MEASUrement:MEAS<x>:REFLevel:METHod
Arguments
<NR3> is the mid reference level, ranging from 0 to 100%. The default mid
reference level is 50%.
Examples
MEASUREMENT:MEAS1:REFLEVEL :PERCENT:MID2
40
sets the mid2 reference
level to 40% of HIGH.
MEASUREMENT:MEAS1:REFLEVEL :PERCENT:MI
D2?
might return
:MEASUREMENT:MEAS1:REFLEVE L:PERCENT:MID2 45, indicating that the
percentage mid2 reference level is set to 45% of HIGH.
MEASUrement:MEAS<x>:SOUrce<x>
This command sets or queries the source for all single channel measurements and
specifies the reference source to measure “to” when taking a delay measurement
or phase measurement. Measurements are
specified by x, which ranges from 1
through 8. This command is equivalent to selecting Measurement Setup from the
Measure menu, selecting a measurement type of either Phase or Delay, and then
choosing the desired measurement source.
Tip: Source2 measurements apply only to phase and delay measurement types,
which require both a target (Source1) and reference (Source2) source.
Group
Measurement
Syntax
MEASUrement:MEAS<x>:SOUrce <x>
{CH<x>|MATH<y>|REF<x>|HISt ogram}
MEASUrement:MEAS<x>:SOUrce <x>?
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-393
