Tektronix DSA70000/B Series Programmer's Manual

Command Groups
Command
Description
HORizontal:FASTframe:REF:FRAme Sets or returns the FastFrame reference
frame number
HORizontal:FASTframe:REF:SOUrce Sets or returns the FastFrame Reference
waveform sou
rce
HORizontal
:FASTframe:SE LECTED:CH<x>
Sets or retu
rns the FastFrame selected
frame number on the specified waveform
HORizontal:FAST frame:SE LECTED:
MATH<x>
Sets or returns the FastFrame selected
frame number on the specified waveform.
HORizontal:FAST frame:SE LECTED:
REF<x>
Sets or returns the FastFrame selected
frame num
ber on the specified waveform
HORizont
al:FASTframe:SE LECTED:
SOUrce
Sets or r e
turns the FastFrame source
waveform
HORizontal:FASTframe:SE Quence Sets or r eturns the F astFrame source
waveform
HORizontal:FASTframe:STATE Sets or returns the state of FastFrame
acquis
ition
HORiz
ontal:FASTframe:SUMFrame
Sets o
r returns the summary frame mode
HORiz
ontal:FASTframe:TIMEStamp:ALL:
<wfm>?
Retur
ns the frame number and time stamp
for each frame between requested frames,
inclusive, within the specified waveform
HORizontal:FASTframe:TIMEStamp:
BETW
een:<wfm>?
Returns the relative trigger for the delta time
betw
een the specified frames, within the
specified waveform
HORizontal:FASTframe:TIMEStamp:DELTa:
<wfm>?
Ret
urns the relative time between the
triggers of the FastFrame Selected and the
FastFrame Reference, within the specified
wav
eform
HO
Rizontal:FASTframe:TIMEStamp:
FRAMe:<wfm>?
Returns the absolute trigger date and time
fo
r the specified frame and waveform
HORizontal:FASTframe:TIMEStamp:REF? Returns the absolute trigger date and time for
the F astFrame specified reference w aveform
HORizontal:FASTframe:TIMEStamp:
SELECTED:<wfm>?
Returns the absolute trigger date and time for
the FastFrame Selected, within the specified
waveform
HORizontal:FASTframe:TRA Ck Sets up or returns the state of FastFrame
tracking
HORizontal:FASTframe:XZEro:ALL:CH<x>? Returns the time from the trigger to the start
of the specified frames on the specified
channel
HORizontal:FAST frame:XZEro:ALL:
REF<x>?
Returns the time from the trigger to the start
of the specified frames on the specified
reference
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-25
