Command Groups
Command
Description
MASK:AUTOSet:OFFSETAdj Sets autoset not to enforce the rule that,
for pulse standards, requires 0 V to be in a
certain place
in the mask. Instead, autoset
will attempt to measure the DC offset in
the signal and use scope offset or position
controls to c
ompensate for the DC offset in
the signal
MASK:AUTOSet:STANdard Selects the standard mask in autoset
MASK:AUTOSet:TRIGger Controls if a MA SK:AUTOSet affects the
trigger level
MASK:AUTOSet:USER:ONE Sets or returns the level 1 used by autoset
foruserm
asks
MASK:AUT
OSet:USER:TYPe
Sets or re
turns how autoset scales a mask
MASK:AU
TOSet:USER:ZERo
Sets or r
eturns the level 0 used by autoset
forusermasks
MASK:AUTOSet:VPOS Controls whether the autoset algorithm will
affect the vertical position (or offset) of the
signal
while attempting to autoset
MASK:
AUTOSet:VSCAle
Contr
ols whether the autoset algorithm will
attempt to change the vertical scale while
attempting to autoset
MASK:COPy:USER Copies the currently displayed m ask to the
User
mask
MASK
:COUNt
Rese
ts to zero the number of hits for all mask
segments on the specified source
MASK:COUNt:FAILURES? Returns the number of pass/fail tests that
have failed
MASK:COUNt:H ITS? Returns the total number of mask hits on all
ma
sk segments
M
ASK:COUNt:SEG<m>:HITS?
R
eturns the number of hits in mask segment
<m>
MASK:COUNt:STATE Sets or r eturns the mask hits count state
MASK:COUNt:TESTS? Returns the number of pass/fail tests that
have occurred
MASK:COUNt:TOTal? Returns the sum of all hits in all mask
segments
MASK:COUNt:VIOLATIONS? Returns the number of test violations that
have occurred in the current pass/fail test
MASK:COUNt:WAVEFORMS? Returns the number of waveforms that
have been acquired and processed during
pass/fail testing
MASK:DISplay Sets or returns whether the defined masks
are displayed on the screen
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-33
