Command Groups
Command
Description
MATH<x>:FILTer:RISetime Sets or returns the filter rise time parameter
MATH<x>:LABe
l:NAMe
Sets or returns the label string used for
annotating the displayed math waveform
MATH<x>:LABel:XPOS Sets or returns the X screen offset where the
math wavefo
rm label is displayed
MATH<x>:LA
Bel:YPOS
Sets or retu
rns the Y screen offset where the
math waveform label is displayed
MATH<x>:N
UMAVg
Sets or returns the acquisition number at
which the averaging algorithm will begin
exponent
ial averaging
MATH<x>:
SPECTral?
Returns t
he specified math waveform
spectral setups
MATH<x>:SPECTral:CENTER Sets or returns the center frequency of the
spectral analyzer output data span
MATH<x>:SPECTral:GATEPOS Sets or returns the position of the center of
the gat
e
MATH<
x>:SPECTral:GATEWIDTH
Sets o
r returns the gate w idth input to the
spectral analyzer
MATH<x>:SPECTral:LOCk Sets or returns the s tate of the spectral
locking for the s pecified m ath wav e form
MATH<x>:SPECTral:MAG Sets or returns the units of the SpectralMag
func
tion in the specified math string
MAT
H<x>:SPECTral:PHASE
Set
s or returns the units of the SpectralPhase
function in the specified math string
MATH<x>:SPECTral:REFLevel Sets or returns the vertical position of the
output data from the spectral analyzer
MATH<x>:SPECTral:REFLEVELOffset Sets or returns the spectral reference level
o
ffset used for calculating the dB value
M
ATH<x>:SPECTral:RESBw
S
ets or returns the resolution bandwidth of
the spectral analyzer
MATH<x>:SPECTral:SPAN Sets the top of the frequency span to a value
that is closest to the specified value
Or returns the specified math waveform’s
current frequency span value
MATH<x>:SPECTral:SUPPress Sets or returns the phase suppression
threshold
MATH<x>:SPECTral:UNWRap Enables or disables or returns the state of
the phase unwrap of the spectral analyzer
output data
MATH<x>:SPECTral:WINdow Sets or returns the window function used
to multiply the input data to the spectral
analyzer
2-38 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
