Command Groups
Command
Description
SEARCH:SEARCH<x>:TRIGger:A:RUNT:
THReshold:LOW:REF<x>
Sets or returns the reference waveform
threshold LOW level for a runt trigger search
to determine w
here to place a mark.
<x>
is the search number or the reference
waveform number
SEARCH:SEARCH<x>:TRIGger:A:RUNT:
WHEn
Sets or returns the condition setting for a
runt trigge
r s earch to determine where to
place a mark. <x> is the search number
SEARCH:SEARCH<x>:TRIGger:A:RUNT:
WIDth
Sets or returns the width setting for a runt
trigger search to determine where to place a
mark. <x> i
s the search number
SEARCH:S
EARCH<x>:TRIGger:A:SETHold:
CLOCk:EDGE
Sets or re
turns the clock slope setting for a
setup/hold trigger search to determine where
to place a mark. <x> is the search number
SEARCH:SEARCH<x>:TRIGger:A:SETHold:
CLOCk:S
OUrce
Sets or returns the clock source setting for a
setup/h
old trigger search to determine where
to place a mark. <x> is the search number
SEARCH:SEARCH<x>:TRIGger:A:SETHold:
CLOCk:THReshold:CH<x>
Sets or returns the clock threshold setting
for a setup/hold trigger search to determine
where t
o place a mark. <x> is the search
number or channel number
SEARCH:SEARCH<x>:TRIGger:A:SETHold:
CLOCk:THReshold:MATH<x>
Sets or returns the clock threshold setting
for a setup/hold trigger search to determine
where
to place a mark. <x> is the search
number or math waveform number
SEARCH:SEARCH<x>:TRIGger:A:SETHold:
CLOCk:THReshold:REF<x>
Sets or returns the clock threshold setting
for a setup/hold trigger search to determine
wher
etoplaceamark. <x>isthesearch
number or reference waveform number
SEARCH:SEARCH<x>:TRIGger:A:SETHold:
DATa:SOUrce
Sets or returns the data source setting for a
setup/hold trigger search to determine where
to
place a mark. <x> is the search number
SE
ARCH:SEARCH<x>:TRIGger:A:SETHold:
DATa:THReshold:CH<x>
Se
ts or returns the data threshold setting
for a setup/hold trigger search to determine
where to place a mark. <x> is the search
n
umber or channel number
S
EARCH:SEARCH<x>:TRIGger:A:SETHold:
DATa:THReshold:MATH<x>
S
ets o r returns the data threshold setting
for a setup/hold trigger search to determine
where to place a mark. <x> is the search
number or math waveform number
SEARCH:SEARCH<x>:TRIGger:A:SETHold:
DATa:THReshold:REF<x>
Sets or returns the threshold high voltage
level setting for a transition trigger search
to determine where to place a mark. <x> is
the search number or reference waveform
number
2-50 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
