Command Groups
Command
Description
AUXIn:PRObe:RESistance? Returns the resistance factor of the probe
that is attached to the AUX In input
AUXIn:PRObe:SET Sets or queries aspects of probe accessory
user interfa
ces, for example probe
attenuation factors
AUXIn:PRObe:SIGnal Sets or queries aspects of probe accessory
user interfaces
AUXIn:PRObe:TIPtype Sets or returns the type of probe tip being
used
AUXIn:PR
Obe:UNIts?
Returns a
string describing the units of
measure for the probe attached to the AUX
In input
AUXIn:PROBEFunc:EXTAtten Sets or returns the input-output ratio, of
externa
l attenuation or gain, between the
signal and the AUX In input
AUXIn:PROBEFunc:EXTDBatten Sets or returns the input-output ratio
(expressed in decibel units) of external
attenu
ation or gain between the signal and
the instrument AUX In input
AUXIn:PROBEFunc:EXTUnits Sets or returns the unit of measurement for
the external attenuator of the AUX In input
CH<x>? Returns vertical parameters for the specified
chan
nel
CH&l
t;x>:BANdwidth
Sets
or returns the bandwidth of the specified
channel
CH<x>:BANdwidth:ENHanced Sets or queries either the “Bandwidth
Enhancement (DSP) Enabled” or “Analog
On
ly” option.
CH
<x>:BANdwidth:ENHanced:APPLYtoall
Se
ts or queries whether the enhanced
bandwidth filter applies to all active channels
CH<x>:BANdwidth:ENHanced:FORCe Sets or returns the Force constant sample
rate of the Digital Filters (DSP)
CH<x>:BANdwidth:ENHanced:STATE? Returns the state of the bandwidth
enhancement fi lter
Sets or queries the bandwidth enhancement
filter type
CH<x>:COUPling Sets or returns the coupling setting for the
specified channel
CH<x>:DESKew Sets or returns the deskew time for the
specified channel
CH<x>:LABel:NAMe Defines or returns the label for the channel
waveform
CH<x>:LABel:XPOS Sets or returns the X display c oordinate for
the channel waveform label
2-64 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
