TRENDnet TL2-E284 - Set; Police

24-Port 10/100Mbps Layer 2 Switch w/ 4 Gigabit Ports and 2 Shared Mini-GBIC Slots
37-2
User Guidelines
Class map must be created before associating.
Example
switch(config-pmap)# class 1
Existing Policy-map configurations have been deleted. Please
apply the policy-map to make it active.
switch(config-pmap-c)#
Command History
Version
History
1.00.001
This command was introduced
set
To set the new 802.1p priority or DSCP type of packets match the associated ACL
rule.
Command
set {cos <new-cos(0-7)> | ip dscp <new-dscp(0-63)> }
no set {cos <new-cos(0-7)> | ip dscp <new-dscp(0-63)> }
Syntax Description
cos new-cos(0-7)
Specify the new 802.1p priority of the packet.
ip dscp new-dscp
(0-63)
Specify the new DSCP type of the packet.
Command Modes
Policy-map Class Configuration Mode
Example
switch(config-pmap-c)# set cos 1
Command History
Version
History
1.00.001
This command was introduced
police
To set up the actions of packets match the associated ACL rule.
Command
police <rate-Kbps> exceed-action {drop | policed-dscp-transmit
<new-dscp(0-63)>}
Syntax Description
rate-Kbps
Set the traffic rate threshold in Kbps for the class
map.
exceed-action drop
Drop packets if traffic rate exceeds the threshold.
exceed-action
policed-dscp-transmit
new-dscp(0-63)
Modifying the DSCP type value for packets if traffic
rate exceeds the threshold.
Command Modes
Policy-map Class Configuration Mode
