TRENDnet TL2-E284 - Ip Standard Acl Configuration

24-Port 10/100Mbps Layer 2 Switch w/ 4 Gigabit Ports and 2 Shared Mini-GBIC Slots
7-2
lavc-sca 0x6007(24583).
mop-console 0x6002(24578).
mop-dump 0x6001(24577).
msdos 0x8041(32833).
mumps 0x6009(24585).
netbios 0x8040(32832).
vines-echo 0x0BAF(2991).
vines-ip 0x0BAD(2989).
xns-id 0x0807(2055).
others Insert a custom Ether type (0-65535) to the right column.
Click Add to create a new ACL rule, Reset to clear the value.
Parameter
Description
Select
Select an ACL rule to apply the configuration changes.
ACL Number
Specify the ACL ID of this rule.
Source MAC
Matching packets with a specific source MAC address.
Destination MAC
Matching packets with a specific destination MAC address.
Action
Specify the action for packet matched. Select Permit to process the packets,
Deny to discard them.
VLAN ID
Matching packets with a specific VLAN ID.
Port List (Incoming)
Specify the ports to apply this ACL rule.
Protocol
Matching packet with specific protocol (Ether type). The options are:
Protocol Ether Type
aarp 0x80F3(33011).
amber 0x6008(24584).
dec-spanning 0x8138(33080).
decnet-iv 0x6003(24579).
diagnostic 0x6005(24581).
dsm 0x8309(32825).
etype-6000 0x6000(24576).
etype-8042 0x8042(32834).
lat 0x6004(24580).
lavc-sca 0x6007(24583).
mop-console 0x6002(24578).
mop-dump 0x6001(24577).
msdos 0x8041(32833).
mumps 0x6009(24585).
netbios 0x8040(32832).
vines-echo 0x0BAF(2991).
vines-ip 0x0BAD(2989).
xns-id 0x0807(2055).
others
Protocol Number
Specify the Ether type for the protocol.
Click Apply to submit the changes to the ACL rule, Delete to delete it.
IP Standard ACL Configuration
This page is to create/configure a rule to IP standard Access Control List.
