TRENDnet TL2-E284 - Dynamic VLAN Port Configuration

24-Port 10/100Mbps Layer 2 Switch w/ 4 Gigabit Ports and 2 Shared Mini-GBIC Slots
6-7
Figure 35 – Layer2 Management > Dynamic VLAN > Dynamic VLAN Global Configuration
Parameter
Description
Garp System Control
Choose Start to enable GARP function, and Shutdown to disable it. It is
needed for using dynamic VLAN function. Default is Start.
Dynamic VLAN Status
To set the status of dynamic VLAN function from Enabled or Disabled.
Default is Disabled.
Click Apply to submit the changes.
Dynamic VLAN Port Configuration
This page is to configure dynamic VLAN settings on switch ports.
Figure 36 – Layer2 Management > Dynamic VLAN > Port Settings
Parameter
Description
Port
Specify the switch port to be configured.
Dynamic VLAN Status
To set the status of dynamic VLAN function from Enabled or Disabled.
Restricted VLAN
Registration
To enable/disable the restricted VLAN on an interface.
