TRENDnet TL2-E284 - Conventions

24-Port 10/100Mbps Layer 2 Switch w/ 4 Gigabit Ports and 2 Shared Mini-GBIC Slots
11-22
Configuration
Mode
interfaces.
Config-vlan Mode
The VLAN Configuration Mode is used to configure the commands for VLAN
interfaces.
MSTP
Configuration
Mode
The MSTP Configuration Mode is used to configure multiple spanning tree
specific commands.
MAC Access List
Configuration
Mode
The MAC Access List Configuration Mode is used to configure L2 access rules
including content such as MAC address, VLAN, or specific Ether type.
Standard IP Access
List Configuration
Mode
The Standard IP Access List Configuration Mode is used to configure L3 access
rules with specific source/destination IP address.
Extended IP
Access List
Configuration
Mode
The Standard IP Access List Configuration Mode is used to configure L3/4 access
rules with specific IP address, protocol type or port number.
Class-map
Configuration
Mode
The Class-map Configuration Mode is used to configure class rules and access
lists mapping.
Policy-map
Configuration
Mode
The Policy-map Configuration Mode is used to configure policy mapping for class
rules.
Policy-map Class
Configuration
Mode
The Policy-map Class Configuration Mode is used to configure the actions of
policies.
Conventions
This publication uses these conventions to convey instructions and information:
Command descriptions use these conventions:
- Commands and keywords are in bold text.
- Arguments for which you supply values are in italic.
- Square brackets ([ ]) means optional elements.
- Braces ({}) group required choices, and vertical bars ( | ) separate the alternative
elements.
- Braces and vertical bars within square brackets ([{ | }]) mean a required choice
within an optional element.
