TRENDnet TL2-E284 - GARP Timers Configuration; Mstp; MSTP Global Configuration

24-Port 10/100Mbps Layer 2 Switch w/ 4 Gigabit Ports and 2 Shared Mini-GBIC Slots
6-8
Click Apply to submit the changes.
GARP Timers Configuration
This page is to set the GARP timers on an interface.
Figure 37 – Layer2 Management > Dynamic VLAN > Port Settings
Parameter
Description
Port No
Specify the switch port to be configured.
GarpJoinTime (10 ~
2^30-14)(msecs)
Specify the join time of GARP. Default is 20 milliseconds.
GarpLeaveTime (30 ~
2^31-18)(msecs)
Specify the leave time of GARP. Default is 60 milliseconds.
GarpLeaveAllTime (40
~ 2^31-8)(msecs)
Specify the leave all time of GARP. Default is 100 milliseconds.
Click Apply to submit the changes.
MSTP
MSTP Global Configuration
This page is to configure the MSTP global settings of the Switch.
