Label

84 Manual m600 basic 2.6_01

See Chapter 7.3.3.4, "2/5i".

EAN13/EAN8

This is for specifying whether the barcode appears with or without a

number plain text line.

Fig. 7_137: Example - barcode with and without numerical plain text line

Fig. 7_138: Activation/deactivation of plain text line

Ratio

Display plain text


