Manual m600 basic 2.6_01 7

Fig. 4_7: Optical fiber

Fig. 4_8: HP cartridge

Fig. 4_9: Protective caps for cartridges

Accessories

Fig. 4_10: Mounting kit for 1-head mounting

Fig. 4_11: Adjusting unit for multi-head mounting

The optical fiber is fitted between the

analysis electronics and the scraper

plate.

HP cartridges are available with a

range of types of ink for the different

substrates.

The protective caps protect the noz-

zle plate from mechanical damage

and from drying out in storage.

The mounting kit allows fast and

simple print head mounting.

The accessory part for multi-head

mounting is suitable for all print head

versions. The adjusting unit allows

the print heads to be finely adjusted

for perfect print images.
