Technical data
Manual m600 basic 2.6_01 167
14
Power supplySupply voltage
The user is not required to change the supply voltage. The m600 basic is
adjusted automatically to the available supply voltage.
However, the power plugs of usual local design must be used.
Tab. 14_13: Supply voltage
Type of connection
This m600 basic features a firmly connected power supply cable of approx.
1.8 m length (with grounding plug).
Pulse generator
socket
The pulse generator which can be connected to this socket enables the
m600 basic to determine the speed of the product being printed. To this
effect, see "Settings/System".
The standard pulse generator supplied by Wolke Inks & Printers GmbH de-
livers 2,500 pulses per revolution. Four different drive discs are available
for the pulse generator. If the measurement wheel is positioned directly
on the product conveyor belt, the resultant values are as shown in the ta-
ble below. The number of pulses per meter has to be entered in the "Set-
tings/System" menu.
Tab. 14_14: Values for pulses/meters depending on measuring wheel diameter
Plug-and-socket connectors used
A 12-pole plug-and-socket connector is used for the pulse generator con-
nection.
14.2 Terminals
14.2.1 Power supply
Value Range Tolerance Unit Info
Supply voltage 90-240 ± 10 % V
System frequency 50/60 < ± 1 % Hz
Power rating 60 W
Fuse (F1) 2 A MT
14.2.2 Pulse generator socket
Drive disk model Diameter Standard values
Pulses/m
Aluminium measuring wheel (solid material) 67.33 mm 11.819
Rubber measuring wheel (studded) 63.66 mm 12.500
Solid aluminium with cross spokes 63.66 mm 12.500
Plastic, smooth 63.66 mm 12.500
