Label

Manual m600 basic 2.6_01 129

The setting "Number/Sensor =1" has the same resultant effect as the set-

ting "Cyclic - deactivate".

Other

parameters

Fig. 7_222: Label parameter – Number/Sensor

The following label is to be created as a straightforward example:

Example -

creating a

straight-

forward label

7.6 Example – creating a straightforward label

 "New" is selected to create a

new label.

A template with one print head is

selected.

 Acknowledge via the button

"Select".
