Label
92 Manual m600 basic 2.6_01
7
Datamatrix Excerpt from the list of GS1 Application Identifiers (AI) available:
Tab. 7_6: GS1 Application Identifier - Excerpt
Matrix size
The list for the matrix size allows you to choose whether the code as a
whole should be shown as a square or rectangle. The program then
calculates the minimum size in number of crosswise modules x number of
lengthwise modules.
This size is the minimum size required for showing the content of the code
entered under Datamatrix. If you require the code to be shown with a
larger matrix you can select one from the size list. This means that you
can keep the same size of matrix for products even when the content
varies.
Tab. 7_7: possible matrix sizes of the Datamatrix
ATTENTION
All size specifications in relation to the 2D Datamatrix
code are based on a m600 basic's resolution of 600 x
600 dpi.
AI Complete designation Format
01 GTIN n2+n14
10 Lot/batch number n2+an..20
11 Date of manufacture (YYMMDD) n2+n6
12 Due date (YYMMDD) n2+n6
13 Date of packaging (YYMMDD) n2+n6
15 Best-before date (YYMMDD) n2+n6
17 Expiry date (YYMMDD) n2+n6
21 Serial number n2+an..20
90 Information for application coordinated bilaterally
(including FACT DIs)
n2+an..30
8004 Global Individual Asset Identifier
EAN identification for serial objects
n4+an..30
Matrix size
auto square 18x18 30x30 48x48
auto rectangular 20x20 32x32 8x18
10x10 22x22 34x34 8x32
12x12 24x24 36x36 12x26
14x14 26x26 40x40 16x36
16x16 28x28 44x44 16x48
