Installation

Manual m600 basic 2.6_01 5

Main compo-

nents

Scope of supplies:

If parts are missing or damaged, please conact the agent or your contact

person at Wolke.

Fig. 4_1: Controller

Fig. 4_2: Print heads

The blue print head is suitable for all standard applications.

The red, green and gold colored special-size print heads are designed for

non-standard installation and space situations.

4Installation

4.1 Integral parts and accessories of the m600 basic

 Remove all parts from the cardboard box and remove the packaging

material.

(Avoid damaging the components when using sharp objects to open

the packaging.)

 Check that all parts included in the scope of supplies are present

and in good condition.
