Show current print label

142 Manual m600 basic 2.6_01

Show

current print

label

This menu permits rapid access to the preview of the current label.

The menu buttons + and - can be pressed to scale the view up or down

accordingly.

As standard, the complete label is displayed.

Fig. 10_235: Main menu > Show current print label

10 Show current print label
