Label

Manual m600 basic 2.6_01 87

EAN128/

Code128

Value

This menu item is for entering the digit combination for the barcode.

Text position

You can choose between having the digits shown either below or above

the barcode.

Fig. 7_141: Determination of text position

Distance [mm]

The distance function is for specifying the distance between the barcode

and the plain text line.

Fig. 7_142: Barcode – Defining the distance

Font size [mm]

This defines the height of the text in the plain text line.

Text space 0,5 mm

Text space 1,5 mm
