wolke m600 basic - Fig. 7_213: Head 1

To Next Page

To Previous Page

Label

124 Manual m600 basic 2.6_01

Distance after

The "Distance after" has to be set in order to ensure that the photoelectric

cell is not triggered again before the next product has been detected (e.

g. caused by a black line on the print material). This setting has the effect

of blanking the photoelectric cell.

Label size

Fig. 7_213: Head 1 – Distance after

NOTE

A maximum "distance before" of 400 mm, a maximum

"printing length" of 500 mm and a maximum "distance

after" up to 2000 mm is possible.

1 Print heads 4 Product

2 Photoelectric cell 5 Distance after

3 Print length 6 Distance before

NOTE

For system-related reasons the "Distance after" must not

be less than 5 mm.
