Settings
Manual m600 basic 2.6_01 57
6
Product sensor:
Fig. 6_91: Print head 1 > Product sensor
Here, you define the print head to which the sensor is mounted.
Print heads and
print head con-
figuration
Upside down
Fig. 6_92: Print head 1 > Mirrored
Reflected
Fig. 6_93: Print head 1 > Reflected
OFF:  Letters, normal
ON:  Letters, upside down
OFF:  Letters, normal
ON:  Letters, mirrored
