wolke m600 basic - Scheduled Maintenance for System Components

To Next Page

To Previous Page

Service and maintenance

Manual m600 basic 2.6_01 177

Maintenance

instructions

The controller does not require any maintenance.

ATTENTION

Never use solvent or other liquids to clean the ink car-

tridges.

15.3 Maintenance instructions

Work to be performed Measures

Print head

Check the contact pins visually once per

month for damage/corrosion!

Check the scraper blade visually once per

month for wear!

Check the function of the cartridge locking

lever.

If necessary, replace the print head. Return

the damaged print head to us!

If necessary, replace the scraper plate.

If necessary, replace the locking lever.

Cable

Check all screw-fastened plug-and-socket

connectors for tight fit.

If necessary, retighten them.

Check quarterly the print head calbes in the

cable carriers for visible chafing, wear or

crushed areas.

If necessary, replace the print head cables.
