The inputs and outputs can be configured under "Settings/Installation/

External inputs (see Chapter 6.2.2).

InputsIn addition to the inputs for the two photoelectric cells on the two print

heads, the m600 basic also comes with four additional parameterizable

digital inputs. These four inputs come out at the 24 V I/O socket.

Fig. 8_228: Start diagnosis > Inputs

OutputsThe outputs 1 to 4 can be handled manually.

Fig. 8_229: Start diagnosis > Outputs

8.2 Inputs and Outputs

8.2.1 Inputs

8.2.2 Outputs
