wolke m600 basic - Diagnosis and Troubleshooting; Starting Diagnosis Procedures

To Next Page

To Previous Page

Diagnosis

134 Manual m600 basic 2.6_01

Diagnosis This menu enables you to start diagnosis or to reset the print heads after

a change of cartridge.

Fig. 8_225: Main menu – Diagnosis

Start diagnosis To start the diagnosis for print head 1 or 2, a label must have been loaded

and the "Start" button must be actuated.

Fig. 8_226: Diagnosis > Start diagnosis
