wolke m600 basic - Datamatrix; Fig. 7_148: Barcode Type Datamatrix

To Next Page

To Previous Page

Label

Manual m600 basic 2.6_01 91

Datamatrix

Fig. 7_148: Barcode type Datamatrix

Datamatrix

This field is for entering the characters in the Datamatrix code. The code

is later shown in the display in the form of a square/rectangular

(depending on the matrix selected). The matrix size is directly dependent

on the number of characters entered here!

7.3.3.6 Datamatrix

NOTE

For explanations relating to the menu items marked ,

please refer to Chapter 7.3.1, "Text".

For explanations relating to the menu items marked ,

please refer to Chapter 7.3.3, "Barcodes".




