Fig. 4_3: Connector cable from print head to the controller; one cable/print head

The print head cable is available with straight connectors or with one-sid-

ed right-angle plug.

Fig. 4_4: Scraper plates

Main compo-

nents

Fig. 4_5: Sensor

Fig. 4_6: Adapter plate (left-hand) and spacer plate

Scraper plate, in different versions

for 1 or 2 heads, for installation on

the underside of the print heads. The

high version is for the blue print head

and the low version is for the other

print heads.

The analysis electronics are for de-

tecting the print material and trans-

ferring the print signal.

The adapter plate and the spacer

plate are required if the locating

wheel is used, for mounting the sen-

sor to the print head.
