Field types The following fields can be created:

Text:

Inserting texts, numbers etc. (see Chapter 7.3.1).

Bitmap:

Here, bitmaps are inserted (see Chapter 7.3.2).

Barcode:

This field contains barcodes: EAN13, UPC-A, EAN128, Code128, Code39,

2/5i, EAN8, Datamatrix (see Chapter 7.3.3).

Date:

Here, a date is generated automatically (best-before date, date of manu-

facture, …) (see Chapter 7.3.4).

Time:

Inserting time, production time etc. (see Chapter 7.3.5).

Counter:

Inserting a counter (see Chapter 7.3.6).

Shift:

Here, the appropriate shift can be entered (see Chapter 7.3.7)
