Diagnosis

140 Manual m600 basic 2.6_01

Fig. 8_232: Cartridge reset

Now, the current ink level is 100 % again.

Status displays

of the warning

beacon

The external outputs 1-3 are evaluated.

Fig. 8_233: Various indications of the warning beacon

 Proceed in the same way for print head 2.

8.4 Status displays of the warning beacon

m600 basic is OFF or set

to "STOP"

m600 basic ready for printing Ink alarm

m600 basic error
