Installation

Manual m600 basic 2.6_01 15

Positioning of

print head

The following positions are available when the print heads are installed:

Fig. 4_28: Print head positioning options

Print head

arrangement

Fig. 4_29: Examples – equipment of the m600 basic with two print heads

4.3.1 Positioning of print head

NOTE

It is not possible to print from below (against gravity).

4.3.2 Print head arrangement

print head at the side

print head at the top

print head horizontal

All on one side, left-

hand

1 on the left and 1 on the

right

All on one side, right-

hand

Side and at the top

from top, left-hand

from top, right-hand
