Label

114 Manual m600 basic 2.6_01

Creating a label

Various label templates are saved in the folder "New".

Fig. 7_196: Label templates – Examples

Fig. 7_197: Example – Template 1Head

Fig. 7_198: Preview Demo1

The preview is still empty as no object has been inserted so far.

7.4 Creating a label

 Select "New" to create a new label.

 Select an existing label template using the cursor buttons and ac-

knowledge by "Select".

 Assign a suitable file name.

 After entering the file name, acknowledge by "OK".
