wolke m600 basic - Label Size; Fig. 7_210: Label Settings

To Next Page

To Previous Page

Label

122 Manual m600 basic 2.6_01

Label size

Fig. 7_210: Label settings – Label size head 1

This part of the menu is for setting the three dimensions which determine

the length of the label (specifications in mm):

7.5.3 Label size

1 Recognition of a new product 4 Distance before

2 Product 5 Print length

3 Recognition of the product by the

photoelectric cell

6Distance after
