Technical data
Manual m600 basic 2.6_01 173
14
Technical data for the inputs on the I/O 24 V DC socket
For the input channels of the 24 V DC socket, the reference ground is
connected to contact "E".
Tab. 14_19: Limits for the 24 V input interface
24 V DC socket
Tab. 14_20: Limits for the 24 V DC output interface
Connection examples
Descriptions of how a range of external devices are connected to the
m600 basic, using examples.
Signal light with 5 meter I/O cable:
Tab. 14_21: Connection example Signal light with 5 meter I/O cable
V
inL
Input voltage "Low level" 0…+5 V
V
inH
Input voltage "High level" + 20…+ 28 V
I
in max.
max. input current max. 20 mA
t
p
Signal make-time min. 25
s
NOTE
The time given in the table refers to the use of the input
as a signal for the start of printing.
U
out int
Output voltage of the m600 basic driver 24 V DC
V
out ext.
max. external voltage for power supply
to the m600 basic power driver
50 V DC
I
out max.
max. continuous output current (sum of
outputs)
200 mA
I
out max.
max. peak output current for 3 seconds 0,8 A
PIN on the
m600 basic
Function Cable colour Jumper Contact of si-
gnal lamp
PVCCwhite/yellowXnc
JExt.: +24VblackXnc
TGNDbrownX0
AExt. GNDgrayX0
OOutput 1
m600 basic OK
green/brown 1
ROutput 2
m600 basic
Error
yellow/brown 3
SOutput 3
m600 basic
Alarm
white 2
