Installation

8 Manual m600 basic 2.6_01

The resilient print head suspension element ensures that the printing dis-

tance is always optimized whatever the product position.

Fig. 4_12: Parallelogram with locating wheel

Accessories An alternative to the locating wheel is the deflector (see illustration). Both

of these components facilitate initial distance compensation which goes

easy on the material. Either the locating wheel or the deflector are used

depending on the specific application.

Fig. 4_13: Deflector and locating wheel

Fig. 4_14: Pulse generator

vertically mounted horizontally mounted

The pulse generator is for measur-

ing the product speed and therefore

for adjusting the print to different

speeds.
