Information

Symbol-

and

information

notes

In this operating manual, the following designations and symbols are used

to indicate hazards:

NOTE

This symbol represents information which is to facilitate

operation or compliance with which may improve the op-

erating procedures.

ATTENTION

Information which, if not observed, may result in damage

or destruction of the device or in damage to property.

WARNING

Information which, if not observed, may result in a health

hazard for the operator.

INFORMATION ON CARE

This symbol indicates important information about how to

care for the m600 basic correctly. Non-observance of this

information may result in faults in the operation of the

m600 basic or its environment.
