Screen messages

Manual m600 basic 2.6_01 189

Do you want to transfer the

update?

This query appears if the function Loading >complete

has been selected in the menu "File management".

Please wait Displayed during the update process

Please remove memory

stick

Remove memory stick after copying an update

Please, first press Stop Press Stop to load a new label

Saving

failed

Saving of file failed

Error on copying file Error occurred when copying the file

Please check user

authorization

After the update, the user authorizations must be

checked

Do you want to

save now?

If changes have been performed to the label, the

system queries after exiting the menu whether these

changes are to be saved.

Do you really want to

delete the object / file?

This safety query appears if an object (e. g. a text field)

or a label is to be deleted.

Message/Note Meaning/Reason
