Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-76
790 401 DIAG_G3M_RX_RESO Resolution
Setting Upon
Receive
0-128 0x00: Normal
0x80: R8x3.85
821 412 DIAG_PAGE_MARGIN_REDUCTI
ON
Page Split Margin
(Reduction: ON)
0-127
825 001 DIAG_NCU_TYPE NCU Type 0,1
825 004 DIAG_DP_RELAY_DELAY Interval Until
Relay Switch
(Interval Until
Steady Line)
Upon Pulse Dial
0-255
825 005 DIAG_DRPD_ENABLE Allow/Restrict
DRPD Setting
0,1
825 013 DIAG_DIS_DP_20PPS 20PPS Pulse Dial 0,1
825 015 DIAG_CNG_DETECT_TIME CNG Detect Time 0-255
825 016 DIAG_AUTO_ANSWER_TIME External Phone
Calling Time
(Time to output
ringing sound
from speaker
when unable to
detect CNG after
starting to call)
0-255
825 025 DIAG_RING_CYCLE_MIN (14/0.5) Ring
Signal Cycle
Minimum Value
0-255
825 026 DIAG_RING_CYCLE_MAX (100/0.5) Ring
Signal Cycle
Maximum Value
8-255
825 027 DIAG_SELECT_DIALTONE Dial Tone
Frequency
0-3
825 028 DIAG_BUSYTONE_FREQ Busy Tone
Frequency
0-4
825 029 DIAG_BUSYTONE_PATTERN Busy Tone
Pattern
0-8
825 030 DIAG_BUSYTONE_DETECTION Allow/Restrict
Busy Tone
Detection Upon
Calling
0,1
Parameter List
Chain Link Parameter Name Range
Facy
Def’lt
Note
