Xerox WorkCentre 6605

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-80
825 201 DIAG_NCU_COUNTRY_RELAY NCU Country
Setting - Relay
Setting
0,1
825 202 DIAG_DAA_REG732 FastEdgePulseDia
l2
0,2
825 203 DIAG_DAA_REG_EMI DAA SSD Register
0x02 Setting
0-255
825 601 DIAG_LINE_MONITOR_ENABLE Line Monitor
Setting
0,1
825 604 DIAG_CED_DETECT_TIMER CED Detect Time 25-255
825 666 DIAG_MANUAL_CNG_SIGNAL Manual Send
CNG
Transmission
0,1
825 605 DIAG_CNG_STOP_SELECT CNG
Transmission
Stop Judge
Selection
0,2
825 608 DIAG_RTN_TX_RATE RTN Command
Transmission
Standard (Rate)
0-100
825 609 DIAG_RTN_TX_LINE RTN Command
Transmission
Standard (Serial
Line Number)
0-255
825 610 DIAG_G3M_CALL_T1_TIMER T1 Timer Value
Soon After
Calling
0-255
825 611 DIAG_G3M_TX_T1_TIMER T1 Timer Value
Upon Sending
0-255
825 612 DIAG_G3M_RX_T1_TIMER T1 Timer Value
Upon Receiving
0-255
825 613 DIAG_G3M_T2_TIMER T2 Timer Value 0-255
825 614 DIAG_G3M_T3_TIMER T3 Timer Value 0-255
825 615 DIAG_G3M_AUTO_T4_TIMER Auto
Send/Receive T4
Timer Value
0-255
Parameter List
Chain Link Parameter Name Range
Fac’y
Def’lt
Note
