Xerox WorkCentre 6605

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-81
825 616 DIAG_G3M_MAN_T4_TIMER Manual
Send/Receive T4
Timer Value
0-255
825 617 DIAG_G3M_IVL_TIMER Silent Time Timer
Value
0-255
825 618 DIAG_G3M_FSK_CHK_TIMER FSK Observation
Timer Value
0-255
825 619 DIAG_ITUT_PIX_DELAY Image
Information Send
Delay Time
0-255
825 620 DIAG_G3M_DROP_OUT_TIMER Image
Information
Receive Dropout
Observation
Timer Value
0-255
825 621 DIAG_G3M_NSF_DIS_TIME NSF/DIS
Transmission
Time
0-3
825 622 DIAG_G3M_TX_MODEM_SPEED Communication
Mode Upon
Sending (Speed)
0-5
825 623 DIAG_G3M_RX_MODEM_SPEED Communication
Mode Upon
Receiving (Speed)
0-5
825 625 DIAG_G3M_DIS_IGNORE_NODIS Ignore Times0-255
825 626 DIAG_G3M_TSI_CIG_MODE TSI/CIG Send
Timing
0-2
825 627 DIAG_G3M_WITH_CSI CSI Send 0,1
825 628 DIAG_G3M_FTT_FALLBACK Number of FTT
Until Fallback
0-2
825 629 DIAG_G3M_TCF_CHECK TCF Signal Judge
Standard
0,1
825 630 DIAG_G3M_TX_CABLE_EQU Send Cable
Equalizer
0-3
825 631 DIAG_G3M_RX_CABLE_EQU Receive Cable
Equalizer
0-4
825 632 DIAG_G3M_TAP_HOLD TAP HOLD 0,1
825 633 DIAG_G3M_V29_EPT EP Tone 0,1
Parameter List
Chain Link Parameter Name Range
Fac’y
Def’lt
Note
