Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-96
016 759 Auditron -
Reached Limit
Reached the limit of the
number of registered
users.
Limit Exceeded
Press Ok Button
Error 016-759
Press Ok Button
Replace the
IP Board.
016 799 Job Environment
Violation
Print condition conflicts
with other condition.
Invalid Job
Press Ok Button
Error 016-799
Press Ok Button
Replace the
IP Board.
016 920 Wireless Setting
Error
Timeout Error
Wi-Fi Timeout
Press Ok Button
Error 016-920
Press Ok Button
Replace the
IP Board.
016 921 Wireless Setting
Error
Download Error
Wi-Fi DL Error
Press Ok Button
Error 016-921
Press Ok Button
Replace the
IP Board.
016 922 Wireless Setting
Error
Session Overlap
Error
Wi-Fi SessionErr
Press Ok Button
Error 016-922
Press Ok Button
Replace the
IP Board.
016 923 Wireless
Password Error
Wireless Password is
wrong
Wi-Fi Password
Error
Error 016-923
Press Ok Button
Replace the
IP Board.
016 930 Warning when
unsupported
device is installed
to USB host
• Detect installation of
device of which class
driver cannot be
found.
• Detect installation of
device that class
driver judges not to
support.
• Detect installation of
Low-Speed device.
USB Memory Error
Unsupported
Error 016-930
Unsupported
Replace the
IP Board.
016 931 Warning to
installation of
hub that cannot
be used to USB
host.
Detect installation of
hubs in more than
supported number of
stacks.
USB Memory Error
Unsupported
Error 016-931
Unsupported
Replace the
IP Board.
Phaser 6600 Error Code List
Chain Link Error Error Details Control Panel Messages FIP location

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
