Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-97
016 982 Disk Full RAM Disk Full
Press Ok Button
Error 016-982
Press Ok Button
Replace the
IP Board.
024 340 IOT Firmware
Error
Detect Firmware Error MCU Firmware Err
Power Off/On
Error 024-340
Power Off/On
Page 2-178
024 360 MCU DownLoad
Error
MCU-F/W download
failure
Download Error
Send FW Data
Error 024-360
Send FW Data
-
024 362 IOT Start Image
Marking Timeout
IOT internal error. IOT Start Error
Power Off/On
Error 024-362
Power Off/On
Page 2-190
024 371 IOT-ESS
Communication
Fail
Communication fail
between IOT and ESS.
MCU Comm. Error
Power Off/On
Error 024-371
Power Off/On
Replace the
IP Board.
024 920 <IOT Standard
Stacker Full>
Center Tray Full is
Detected.
Output Tray Full
Remove Paper
Page 2-190
024 927 Mono only mode
reached Limit
Mono only mode (plural
color toners are empty)
reached Limit
PluralTonerEmpty
ReplaceCartridge
Replace Toner
Cartridges.
024 947
948
Tray Detached Tray 1 : 947
Tray 2 : 948
TrayN Missing
Insert TrayN
Error 024-xxx
Insert TrayN
Insert the
tray.
027 446 IPv6 duplicate At start-up, detect
duplicate IPv6 address
on network.
XXXXXXXXXXXXXXXX
IPv6 Duplicate
Replace the
IP Board.
027 452 IPv4 duplicate At start-up, detect
duplicate IPv4 address
on network.
XXXXXXXXXXXXXXXX
IPv4 Duplicate
Replace the
IP Board.
Phaser 6600 Error Code List
Chain Link Error Error Details Control Panel Messages FIP location

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
