Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-99
050 112 MSI Paper Jam Detected
Zone MSI
Paper Jam
Open BypassTray
and Tray1,
remove paper.
1. Pull out
papers on the
Bypass Tray
2. Pull out
Bypass Tray
3. Pull out
Tray1
4. Remove
any jammed
paper
5. Push Tray1
back in
6. Push
Bypass Tray
back in
050 121 IOT Remain Zone
1T JAM
Paper Jam Detected
Zone 1T
Paper Jam
Open Tray1
and remove paper
PressOK to start
Open Tray1 &
Remove
paper
050 122 IOT Remain Zone
2T JAM
Paper Jam Detected
Zone 2T
Paper Jam
Open Tray2
and remove paper
Open Tray2 &
Remove
paper
Phaser 6600 Error Code List
Chain Link Error Error Details Control Panel Messages FIP location

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
