Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-100
050 129 IOT Rear Cover
and MSI
Paper Jam Detected
Zone IOT RearCover and
MSI
Paper Jam
Open BypassTray,
Tray1, RearCover
and remove paper
1. Pull out
papers on the
Bypass Tray
2. Pull out
Bypass Tray
3. Pull out
Tray1
4. Remove
any jammed
paper
5. Push Tray1
back in
6. Push
Bypass Tray
back in
7. Open the
Rear Cover if
cannot
remove any
jammed
paper
8. Remove
any jammed
paper
9. Close the
Rear Cover
061 370 IOT ROS Failure Detect ROS Failure Laser Error
Power Off/On
Error 061-370
Power Off/On
Page 2-179
071 100 IOT Tray1
Misfeed JAM
Detect Tray1 Misfeed
JAM
no message Page 2-192
072 100 IOT Tray2
Misfeed JAM
Detect Tray2 Misfeed no message Page 2-193
072 101 IOT Path2 SNS
On JAM
Detect Path2 SNS On
JAM
no message Page 2-193
072 211 IOT Option
Feeder2 Failure
Detect Feeder2 Failure Tray2 Error
Power Off/On
Error 072-211
Power Off/On
Page 2-178
075 100 MSI Misfeed JAM Detect VSYNC On
JAM(TBD)
no message Page 2-195
Phaser 6600 Error Code List
Chain Link Error Error Details Control Panel Messages FIP location

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
