Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-192
071-100 IOT Tray1 Misfeed JAM
Step Check Yes No
Possible causative parts:
• Regi Sensor [Regi Chute Assembly] (PL15.2.1)
• Feed Clutch (PL15.2.6)
• Paper Transport Motor [Drive Assembly] (PL3.1.1)
• Feed Roller Assembly (PL15.2.7)
• Tray Retard Holder Assembly (PL9.1.3)
• Regi Harness Assembly (PL15.2.8)
• MCU Board (PL18.1.13)
1 Check the Tray 1 installation
Is Tray 1 installed properly?
Go to step 2. Install Tray 1
properly.
2 Check the paper path
Are there any foreign objects, or paper pieces, etc. on the
paper path?
Remove the
foreign objects,
or paper pieces,
etc.
Go to step 3.
3 Check the paper feed roller
Is the paper feed roller (the roller on the possible causative
parts list) installed properly?
Go to step 4. Reinstall the
paper feed roller.
4 Check the paper feed roller
Is the paper feed roller (the roller on the possible causative
parts list) deformed or worn out?
Replace the
paper feed roller.
Go to step 5.
5 Check the Regi Sensor operation
Execute Digital Input diagnostic test 071-103, and check the
Regi Sensor operation.
Does the Regi Sensor function normally?
Go to step 6. Refer to
page 2-211.
6 Check the Feed Clutch operation
Execute Digital Output diagnostic test 071-008, and check
the Feed Clutch operation.
Does the Feed Clutch function normally?
Go to step 7. Refer to
page 2-211
7 Check the Paper Transport Motor operation
Execute Digital Output diagnostic test 071-004, and check
the Paper Transport Motor rotation.
Does the Paper Transport Motor function normally?
Replace the MCU
Board.
Refer to
page 2-181.

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
