Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-181
042-326 IOT Motor Failure
Step Check Yes No
Possible causative parts:
• Paper Transport Motor [Drive Assembly] (PL3.1.1)
• Drive Harness Assembly (PL18.2.2)
• Top Harness Assembly (PL18.2.5)
• LVPS (PL18.1.34)
• MCU Board (PL18.1.13)
1 Check the Paper Transport Motor operation
Execute Digital Output diagnostic test 071-004, and check
the Paper Transport Motor rotation.
Does the Paper Transport Motor function normally?
Replace the MCU
Board.
Go to step 2.
2 Check the Paper Transport Motor connection
Check the connection between the Paper Transport Motor
and the LVPS, and the connection between the Paper
Transport Motor and the MCU Board.
Are P/J312, P/J509, P/J172, and P/J17 connected securely?
Go to step 3. Connect P/J312,
P/J509, P/J172,
and P/J17
securely.
3 Check the continuity between the Paper Transport Motor
and the MCU Board
Is each cable of P/J172<=>P/J17 continuous?
Go to step 4. Replace the Drive
Harness
Assembly.
4 Check the continuity between the Paper Transport Motor
and the LVPS
Is each cable of P/J312<=>P/J509 continuous?
Go to step 5. Replace the Top
Harness
Assembly.
5 Check the power to the Paper Transport Motor (+24 VDC)
Close the interlock switch(es), and check if the voltage
between the LVPS ground and the P/J509-3 pin is about
+24 VDC.
Replace the Drive
Assembly.
Replace the LVPS.

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
