Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-182
093-320 IOT Developer Motor Fail
Step Check Yes No
Possible causative parts:
• Developer Motor [Drive Assembly] (PL3.1.1)
• Drive Harness Assembly (PL18.2.2)
• Top Harness Assembly (PL18.2.5)
• LVPS (PL18.1.34)
• MCU Board (PL18.1.13)
1 Check the Developer Motor operation
Execute Digital Output diagnostic test 093-001, and check
the Developer Motor rotation.
Does the Developer Motor function normally?
Replace the MCU
Board.
Go to step 2.
2 Check the Developer Motor connection
Check the connection between the Developer Motor and the
MCU Board.
Are P/J331 and P/J33 connected securely?
Go to step 3. Connect P/J331
and P/J33
securely.
3 Check the continuity between the Developer Motor and the
MCU Board
Is each cable of P/J331<=>P/J33 continuous?
Go to step 4. Replace the Drive
Harness
Assembly.
4 Check the power to the Developer Motor (+24 VDC)
Close the interlock switch(es), and check if the voltage
between the MCU Board ground and the P/J33-2 pin, and
the voltage between the MCU Board ground and the P/J33-4
pin is about +24 VDC.
Replace the Drive
Assembly.
Replace the LVPS.

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
