Xerox WorkCentre 6605 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-147
033 791 Cancel Cancel Fax Job Canceled 033-791
* Caution screen with [Close]
button
Replace the
Fax Board.
033 795 FAX Send Count
Limit
Reach the upper limit of
Fax send accumulation
pages.
Fax Send Error 033-795
Maximum number of send pages
has been exceeded.
Job canceled. Please wait then try
again.
* Caution screen with [Close]
button
Replace the
Fax Board.
033 799 In MH,HR,MMR receive,
exceed the maximum
number of received lines
for 1 page.
Fax Codec Error 033-799
Maximum number of received
lines for one page exceeded.
Job canceled. Remote device will
try again.
* Caution screen with [Close]
button
Replace the
Fax Board.
034 508 Command Refuse
Signal Send
Send command refuse
signal to stop
communication.
Fax Communication Error 034-
508
Refused command signal sent
Job canceled. Please try again.
* Caution screen with [Close]
button
Replace the
Fax Board.
034 515 DIS DCS Illegal
Command
Receive
Receive illegal command
such as DIS, DCS receive
from calling terminal in
spite of having no ability
to receive.
Fax Communication Error 034-
515
Digital identification signal or
Digital command signal had illegal
command.
Job canceled. Remote device will
try again.
* Caution screen with [Close]
button
Replace the
Fax Board.
034 791 Check Line
Connection
Fax Line fail. Check the
plug and connection.
No Answer 034-791
Check Line Connection. Please
disconnect and reconnect fax line
to insure proper connection.
Job canceled.
* Caution screen with [Close]
button
Replace the
Fax Board.
WorkCentre 6605 Error Code List
Chain Link Error Error Details Control Panel Messages
FIP
location

Xerox WorkCentre 6605 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	Up to 600 x 600 x 4 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Standard Paper Capacity	550 sheets
Maximum Paper Capacity	1, 250 sheets
Paper Output	250 sheets
Duplex Printing	Yes
Processor	533 MHz
Memory (Standard)	512 MB
Memory (Maximum)	1 GB
Monthly Duty Cycle	Up to 80, 000 pages
Type	Multifunction
Copy Speed	Up to 36 cpm black and color
Fax Resolution	300 x 300 dpi
Media Sizes	Letter, Legal, A4, A5, B5, Custom sizes
Connectivity	USB 2.0, Ethernet
Mobile Printing	Apple AirPrint
Operating System Compatibility	Windows, Mac, Linux
Dimensions (W x D x H)	500 mm
Weight	29.6 kg
Print Speed	Up to 36 ppm (Black) / Up to 36 ppm (Color)
